 SeaBotix Inc. SeaBotix Inc. is the leading manufacturer of the MiniROV system LBV and revolutionary hybrid ROV/Crawler. A truly capable small ROV system that bridges the gap between small ROV portability and large ROV performance. | |
 |
|
| SeaBotix Product Line | |
 |
LBV150BE 2 The ideal inshore system offering high performance, ease of operation, compact dimensions and low cost. Perfect for those shallow water operations such as port/harbor inspections, potable water and education. Depth Rating: 150m - 500ft Umbilical: 75m - 328ft Thrusters: 4 HPDC more info |
|
|
|
LBV150S 2 A great two case solution to inshore operations. Upgraded to the integrated console and 150 meter umbilical for a well rounded yet capable MiniROV system. Depth Rating: 150m - 500ft Umbilical: 150m - 500ft Thrusters: 4 HPDC more info |
|
|
|
LBV150SE 2 The small ROV system by which all are compared. Perfectly equipped for a diverse range of applications including Maritime Security, Aquaculture, Search and Rescue and many more. Complete with all the key features. Depth Rating: 150m - 500ft Umbilical: 175m - 574ft Thrusters: 4 HPDC more info |
|
|
 |
LBV150SE-5 2 Enhanced version of the LBV150SE2 offering the added vertical thruster for more power and control. The most stable small ROV that is suited to a very diverse range of applications. Depth Rating: 150m - 500ft Umbilical: 175m - 574ft Thrusters: 5 HPDC more info |
|
|
|
LBV200L 2 An excellent combination of performance, long umbilical length, depth rating and price. A well rounded system offering the operator extended excursion capabilities, current fighting thrusters and crystal clear fiber video. Depth Rating: 200m - 660ft Umbilical: 250m - 820ft Thrusters: 4 HPDC more info |
|
|
 |
LBV300S2 Deeper depth rating and longer umbilical provide extended capabilities still in a very compact system. A well suited system for those farther to reach applications such as offshore oil and gas. Depth Rating: 300m - 1,000ft Umbilical: 350m - 1,148ft Thrusters: 4 HPDC more info |
|
|
 |
LBV300S-6 2 An amazing amount of power for fighting those harsh conditions. When the application demands more thrust the additional two forward thrusters make this system the ideal choice. Still very portable. Depth Rating: 300m - 1,000ft Umbilical: 350m - 1,148ft Thrusters: 6 HPDC more info |
|
|
|
LBV300XL 2 Taking the added thrust of two additional forward thrusters and combined with an extra long umbilical make this system unbeatable in long line penetrations. Capable of small diameter pipeline inspections or exterior work. Depth Rating: 300m - 1,000ft Umbilical: 750m - 2,460ft Thrusters: 6 HPDC more info |
|
|
 |
LBV600XL2 The rapid response deep water free flying solution available. Deep depth capability, tremendous amount of power and extended cable length make this system the perfect deep water rescue aid. ` Depth Rating: 600m - 2,000ft Umbilical: 750m - 2,460ft Thrusters: 6 HPDC more info |
|
|
 |
LBV150SE-5 2 with Crawler Skid A truly unique combination of ROV and Crawler. Utilize the system in ROV mode for free swimming inspections or attach to hard surfaces for precision control not available in conventional ROV systems. Depth Rating: 50m - 165ft Umbilical: 175m - 574ft Thrusters: 5 HPDC more info |
|
|
